Inline ink viscosity measurement
The inline viscometer measures ink viscosity in a flowing sample, at a controlled temperature. It provides flow curves for formulation work and real-time readings for small-batch quality control.
This application pack combines our inline viscometer with all-PEEK cartridges, sample-handling components and logging software. An optional microfluidic flow sensor can be added to the same setup.
Ink flow curves from low shear to handling conditions
Many pigmented and functional inks are shear-thinning. Their viscosity changes with shear rate, so one reading cannot describe the whole flow curve. Low-shear behaviour informs investigations of settling, sag and leveling, while higher-shear measurements help characterise pumping and handling.
Research on particle-loaded catalyst inks shows why both shear rate and recovery time matter for settling and coating behaviour [1]. Readings down to 1 s⁻¹ support formulation comparisons. Storage stability and thixotropic recovery also require appropriate time-dependent tests.
Small samples at a controlled temperature
Screening experimental UV-curable inkjet inks can mean comparing many monomer and reactive-diluent ratios in small batches. Published formulation screening has used just 0.5 mL per candidate [2]. The viscometer measures from 0.1 mL, with the sample recoverable after the run.
The instrument covers 0.2 to 100,000 cP, with a controlled setpoint within 10 to 70°C. Compare formulations at the same temperature, or repeat measurements at different setpoints to study viscosity versus temperature.
How the measurement works
Flow rate sets the shear rate inside the measurement channel. Stepping through flow rates gives viscosity as a function of shear rate. Holding a measurement condition provides a viscosity trace over time.
The standard shear range is about 1 to 1000 s⁻¹. A high-shear configuration extendable up to 10⁵ s⁻¹ is available on request. Inkjet studies show that inks with similar low-shear viscosity can differ substantially at jetting shear rates [3].
Readings appear on the instrument screen and are logged through the software, with CSV export. Automated drift and clogging detection flags conditions that may affect measurement reliability.
What's included
Inline viscometer
Single-use disposable all-PEEK cartridges
Reservoirs, tubing and fittings
Dedicated software with real-time display and data logging
User guide and technical spec sheet
Optional inline flow sensor
Connect the instrument between your reservoir or syringe and the downstream chip or collection vessel. It works with pressure-driven, syringe or peristaltic pumps.
Use a fresh cartridge for each sample to limit carryover. For inline monitoring, MIC scopes the connection around your line pressure, flow conditions and ink.
Ink viscosity applications
Formulation and small-batch quality control
- Mapping shear-thinning flow curves for pigmented screen, flexo and gravure inks.
- Comparing low-shear viscosity when investigating pigment settling, sag, leveling and storage stability.
- Characterising small batches of silver or copper nanoparticle conductive inks while recovering the sample.
- Measuring UV-curable formulations, printable bio-resins and multi-composition liquids for material jetting.
- Tracking viscosity at fixed shear and temperature to identify changes within or between batches.
Printable resin droplets in VOXWRITE
In the VOXWRITE project, MIC develops a microfluidic sequential injection device that produces resin droplets with varying compositions for multi-material 4D printing. The work brings MIC into direct contact with polymerisable liquids and the flow conditions needed to generate droplets.
For formulators developing such liquids, a shear-resolved viscometer provides viscosity data to guide flow and droplet trials. The practical case illustrates MIC’s work on printable-material delivery; it does not establish that this viscometer was used in VOXWRITE.
The inline viscometer was developed within GALILEO, coordinated by MIC under the EIC Transition programme. The same instrument platform also serves the whole-blood viscosity application pack.
Inline viscometer technical specifications
| Parameter | Value |
|---|---|
| Measurement | Shear-resolved viscosity (high-shear and low-shear), set by flow rate |
| Viscosity range | 0.2 to 100,000 cP |
| Shear rate range | About 1 to 1000 s⁻¹, extendable to 10⁵ s⁻¹ on request |
| Low-shear reach | Reliable readings down to 1 s⁻¹ |
| Viscosity resolution | 0.01 cP |
| Accuracy | Better than 5% of reading |
| Repeatability | Better than 2% |
| Minimum sample volume | 0.1 mL |
| Operating temperature | 10 to 70°C, controlled setpoint |
| Maximum operating pressure | 4 bar |
| Monitoring rate | Continuous logging at up to 100 Hz |
| Compatible pumps | Pressure-driven, syringe, or peristaltic |
| Sample | Recoverable after the run |
| Readout | Real-time on-device screen, software logging and CSV export |
| Connection | USB to a standalone software interface |
| Fittings | Standard microfluidic fittings (1/4-28 or Luer) |
| Chips | Works with commercial or home-made chips |
| Wetted path | Single-use, disposable cartridge, all-PEEK version for solvent-based inks |
| Cleaning | Sanitization protocol, or discard after use |
| Footprint | Compact benchtop unit (10 cm × 10 cm × 6 cm) |
